30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant

30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant

    • 30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant
    • 30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant
    • 30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant
    • 30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant
  • 30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant

    Product Details:

    Place of Origin: China
    Brand Name: HNJZ
    Certification: CE
    Model Number: 30ton

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 300000-500000 per set
    Packaging Details: naked package
    Delivery Time: 45 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 30 sets per month
    Contact Now
    Detailed Product Description
    Raw Material: Waste Tyre And Plastic, Rubber End Product: Fuel Oil ,Steel Carbon Black,Steel Wire
    Name: Fully Continuous Waste Tyre/plastic/rubber Prolysis Plant Working Type: Fully Continuous
    24 Hour Handling Capacity: 30ton Per Day 24 Hour Oil Production: 14T
    Heating Way: Directly Heating Cooling Way: Water Cooling
    Water Consumption: 10T/H Noise: ≤85DB(A)
    Area: 47*10*9M

    30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant



    waste tire pyrolysis plant is decomposed into oil vapor by high temperature pyrolysis technology, and the oil vapor enters the cooling system through the oil gas separator, wherein the oil flows to the oil tank, and the pyrolysis gas passes through water seal to the gas recovery system to become the main furnace fuel. Realize continuous production.



    The Project Report



    Raw Material can be processed:

    Waste tyre, Used rubber, Waste plastic (PP,PE,PS, HDPE), Oil sludge,

    Fuel as heating material :

    Wood, Coal, Carbon briquette, Natural gas, Diesel, Fuel oil, Heavy oil

    End product output ( waste tyre as feeding material )

    Fuel oil : 40%-45%

    carbon black : 30%-35%

    waste gas: 3%-5%

    wire: 10%-15%

    Area Covered:

    Machine covered: 300square meters

    All including ( office, storage and ect): 600 square meters

    Operation workers per shift :

    3-4 people

    Technical Specification

    Item 30 ton fully continuous used tyre pyrolysis plant
    Type HNJZ-30
    Capacity 30 T/D
    Operating Temperature ≤650℃
    Material Q345R
    Fuel Consumption in Start 400kg
    Fuel Consumption in Operation 0(the syn gas from the system be burnt by the system itself)
    Heating Way hot air circulation heating
    Tire Requirement tyre piece ≤20mm
    Working Pressure normal pressure
    Methods of Flame Restardant nitrogen blow
    Total Power 190 kw
    Boundary Dimension 14000mm(L)×2250mm(W)×3750mm(H)×2
    Floor Space 36000mm×8000mm
    The Highest Install Elevation 7000mm
    Labor 2-3 people
    Working Life 5-7 year

    Performance Feature

    1. Safety. We treat safety as the first important thing in production.

    1) Two devices to avoid backfire in production: oil-water separator and anti-back fire device.

    2) Vacuum device makes reactor working under ordinary pressure or negative pressure.

    3) Temperature monitoring device to avoid excessive working temperature.

    4) Pressure gage to monitor the pressure. If it goes above a certain level, the bell will alarm and the safety valve will release the pressure automatically.

    5) Carbon black is discharged in a closed situation to avoid catching fire.

    2. Environmental protection 10 ton used tire pyrolysis plant

    1) The flue gas (caused by burning fuel to heat the reactor) will be purified and cooled by dust removal device, then can be released into air through chimney.

    2) The procedure to remove carbon black is working under closed situation to avoid pollution.

    3. Energy saving waste tire recycling pyrolysis plant

    1) The flame path is designed as spiral so that the quantity of heat can be fully used.

    2) The residual gas from pyrolysis is recycled to furnace burning to heating the reactor.

    3) The insulation cover is formed by 3 levels: steel plate, rock wool and refractory cement. Excellent thermal insulation effect helps saving fuel.

    4. Long service life

    1) The material of reactor is Q345R boiler plate with 16/18mm thickness which is produced by Chinese well-known enterprise. The head of reactor and accessories are using one-piece molding shell cover rather than welded plate.

    2) All cutting, rolling and welding works are finished by automatic machines.

    3) We know quite well about the material quality and manufacturing process, that’s why we are confident in the service life of our products.

    4) We also supply installation service, training service and one year warranty.

    Applications
    It is applied to extract fuel oil from waste tires, rubbers, plastics, soles, life garbage, cable skin and so on .
    seperating crude carbon black, steel wires. the sync gas produced can also be recycled to use as fuel to heat reactor, considerable cost of tire plastic plant.

    30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant

    30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant

    30 Ton Full Automatic Continuous Waste Tyre / Tire Pyrolysis To Fuel Oil Plant
