    Product Details:

    Place of Origin: China
    Brand Name: HNJZ
    Certification: IS9001
    Model Number: JL-10 10TPD

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 10000
    Packaging Details: Capacity : 5Tons/day, need 3*40HQ containers
    Delivery Time: 25 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 50 set per month
    Contact Now
    Detailed Product Description
    Product: Waste Oil Distillation Plant Capacity: 5TPD, 10TPD, 20TPD, 30TPD...300TPD
    Working Type: Continuous Working, Semi-Continuous Working Automatic Degree: Fully Automatic, Semi-Automatic
    Applicable Material: Crude Oil, Used Engine Oil, Waste Hydraulic Oil, Plastic Oil, Tyre Oil, Mixed Waste Oil, Other Waste Oil As Customer Required Heating Fuel: Fuel Oil, Natural Gas, Electric, Coal, Firewood
    Reactor Material: Q345R Steel Plate, Alloy Steel Plate Final Product: Diesel
    Vacuum Degree: -0.06-0.09MPa Oil Heating Temp: 175℃-400℃
    Noise: ≤70dB Oil Yield: 85%
    Installation Space: 35m*15m Manpower: 1-2 Person/Shift

    10TPD 10T 10 ton per day Tyre Pyrolysis Oil to Diesel Waste Oil Distillation Plant​



    Semi-Automatic Distillation Plant Can Make Used Engine Oil/Fuel Oil/Crude Oil into Base oil(used engine oil), Syngas, diesel oil, gasoline and heavy oil. It is widely used to deal with waste oil, such as used engine oil, pyrolysis tyre oil, pyrolysis plastic oil, crude oil, waste gear oil, waste ship oil, waste motor oil etc.

    Project Details.
    1. Used engine oil ,tyre pyrolysis oil , plastic oil , crude oil , sludge oil,furnace oil as input raw material.
    2. Synthetic diesel as final product.
    3. 10 ton distillation unit with latest integrated design, fast installation and easy operation.
    4. Exclusive technology and Environmental friendly.
    5. Heating fuel can be coal , wood , oil , gas and electricity.

    SPECIFICATION OF WASTE OIL DISTILLATION PLANT
    Capacity 3 TON , 5 TON , 10 TON , 30 TON ...
    Working type batch type and contnuous type
    Avaiable raw material Pyrolysis oil ,used motor oil , furnace oil , mixed waste oil , hydrulic oil , sludge oil etc.
    Heating fuel coal , wood , pyrolysis oil , natural gas
    Reactor raw material Q245R steel plate , Q345R boiler steel plate or customized support
    Machine landing area 300-400 square meter (various by different capacity)
    Operators 2 workers per shift
    One batch time 17.5-21.5 hours
    Life span 550-750 batches
    Tyre feeding Auto-feeding
    Space cover 300-400sqm
    No.
    End Production
    Yield
    Usage
    1
    Diesel
    73%
    Used for diesel engine
    2
    Gasoline
    12%
    Used for gasoline engine
    3
    Residue Oil
    9%
    * Feeding into Pyrolysis Machine for second Pyrolysis
    * Sold directly for building road
    4
    Non-Condensible Gas
    3%
    Recycle as Heating fuel after treated by Gas-treatment System
    5
    Other
    3%
    * Water and impurity 2%
    * Loss 1%



    Distillation plant works as follows:
    1. Pump waste oil into distillation reactor by oil pump.
    2. Heat the reactor, and the liquid oil will slowly become oil gas, oil gas will go through catalytic chamber and condenser, then diesel will be cooled out first by controlling the temperature over 150 Celsius degrees.
    3.The gasoline will be cooled out when the temperature is below 150 Celsius degrees, the rest of the system is same as pyrolysis system.

    10TPD 10T 10 ton per day Tyre Pyrolysis Oil to Diesel Waste Oil Distillation Plant

    Main Features

    1. Security:
    A. Adopting automatic submerged-arc welding technology and all of the weldings will be detected by the ultrasonic nondestructive testing method.
    B. Adopting manufacture process controlling system on the quality, every manufacture process, manufacture date, operators, etc.
    C. Manual and automatic safety devices include:anti-explosion device, safety valves, emergency valves, pressure and temperature meters, as well as the alarming system.


    2. Environment-friendly:
    A. Emission Standard: Sync Gas Recycling System: Fully burned after recycling and utilization, saving fuel and preventing pollution. National Patent Smoke Scrubbers: water film smoke scrubber, efficient removal of the acid gas and dust of the smoke, environmental friendly to meet related national standards.
    B. Smell during operation: Fully enclosed during the operation
    C. Water pollution: During the operation, the water we use is recycling one to cool down the gas oil and convert into liquid oil in the condensers. No pollution at all.



    3.National Patent, unique heat insulation shell: high efficiency temperature keeping, excellent energy-saving effect.


    4. Semi-continuous operation, less manpower and low lost in operation.


    5. Unique horizontal design, high oil output with about 90% oil yield and 100% conversion rate, highly effective and profitable.

    Picture of final diesel

    10TPD 10T 10 ton per day Tyre Pyrolysis Oil to Diesel Waste Oil Distillation Plant

    The pyrolysis oil with black color after distillation and remove color and smell , we will get synthetic diesel oil with yellow color , which can be used for diesel engines like trucks , tractors , ships etc.
