Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant

Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant

    • Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
    • Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
    • Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
    • Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
    • Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant
  • Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant

    Product Details:

    Place of Origin: China
    Brand Name: HNJZ
    Certification: IS9001
    Model Number: JL-5

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 10000
    Packaging Details: Capacity : 5Tons/day, need 3*40HQ containers
    Delivery Time: 25 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 50 set per month
    Contact Now
    Detailed Product Description
    Product: USED ENGING OIL RECYCLING MACHINE Capacity: 5TPD, 10TPD, 20TPD, 30TPD...300TPD
    Working Type: Continuous Working, Semi-Continuous Working Automatic Degree: Fully Automatic, Semi-Automatic
    Applicable Material: Crude Oil, Used Engine Oil, Waste Hydraulic Oil, Plastic Oil, Tyre Oil, Mixed Waste Oil, Other Waste Oil As Customer Required Heating Fuel: Fuel Oil, Natural Gas, Electric, Coal, Firewood
    Reactor Material: Q345R Steel Plate, Alloy Steel Plate Final Product: Diesel
    Vacuum Degree: -0.06-0.09MPa Oil Heating Temp: 175℃-400℃
    Noise: ≤70dB

    tyre plastic to diesel oil recycling machine black ship fuel oil refining plant​



    Project Details.
    1. Used engine oil ,tyre pyrolysis oil , plastic oil , crude oil , sludge oil,furnace oil as input raw material.
    2. Synthetic diesel as final product.
    3. 10 ton distillation unit with latest integrated design, fast installation and easy operation.
    4. Exclusive technology and Environmental friendly.
    5. Heating fuel can be coal , wood , oil , gas and electricity.

    SPECIFICATION OF WASTE OIL DISTILLATION PLANT
    Capacity 3 TON , 5 TON , 10 TON , 30 TON ...
    Working type batch type and contnuous type
    Avaiable raw material Pyrolysis oil ,used motor oil , furnace oil , mixed waste oil , hydrulic oil , sludge oil etc.
    Heating fuel coal , wood , pyrolysis oil , natural gas
    Reactor raw material Q245R steel plate , Q345R boiler steel plate or customized support
    Machine landing area 300-400 square meter (various by different capacity)
    Operators 2 workers per shift
    One batch time 17.5-21.5 hours
    Life span 550-750 batches
    Tyre feeding Auto-feeding
    Space cover 300-400sqm
    No.
    End Production
    Yield
    Usage
    1
    Diesel
    73%
    Used for diesel engine
    2
    Gasoline
    12%
    Used for gasoline engine
    3
    Residue Oil
    9%
    * Feeding into Pyrolysis Machine for second Pyrolysis
    * Sold directly for building road
    4
    Non-Condensible Gas
    3%
    Recycle as Heating fuel after treated by Gas-treatment System
    5
    Other
    3%
    * Water and impurity 2%
    * Loss 1%



    Distillation plant works as follows:
    1. Pump waste oil into distillation reactor by oil pump.
    2. Heat the reactor, and the liquid oil will slowly become oil gas, oil gas will go through catalytic chamber and condenser, then diesel will be cooled out first by controlling the temperature over 150 Celsius degrees.
    3.The gasoline will be cooled out when the temperature is below 150 Celsius degrees, the rest of the system is same as pyrolysis system.

    Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant

    The pyrolysis oil with black color after distillation and remove color and smell , we will get synthetic diesel oil with yellow color , which can be used for diesel engines like trucks , tractors , ships etc.

    Tyre Plastic To Diesel Oil Recycling Machine Black Ship Fuel Oil Refining Plant

    Environment :

    1. For water, it is used in two parts. In the cooling system, all the water is recycling, some water is evaporate due to high temperature, in some times, we just need to add water, no water emission. In the dedust system, the water is recycling, too.Due to the chemical reaction, the water is cleaned in the pool and recycled to dust removing device. No water emission.

    2. About the gas, it includes two parts. First is the syngas, it is recycled to the furnance for heating, no emission. Another is the smoke, it is caused by the heating material. And it is clearned by water in the dedust system.NO emission, too.

    3. About the carbon black, we do the futher process and our discharging system is fully closed, no slag flies out.No slag emission.

    4. About the noise , we design draft fan with low noise and make it under international standard.

    5. Above all, all the design can reach the international environmenal standard.
