30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant

30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant

    • 30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant
    • 30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant
    • 30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant
    • 30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant
  • 30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant

    Product Details:

    Place of Origin: China
    Brand Name: HNJZ
    Certification: CE
    Model Number: 30ton

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 sets
    Price: USD 400000
    Packaging Details: naked package
    Delivery Time: 30 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: USD 28 sets per month
    Contact Now
    Detailed Product Description
    Type: Continuous Waste Tire & Plastic Waste To Energy Equipment Raw Material: Waste Rubber ,Waste Tire,waste Plastic
    End Product: Fuel Oil, Carbon Black, Steel Wire, Sync Gas Structure: Horizontal Rotation
    Fuel Choice: Coal,wood,gas ,oil Operating Mode: Intermittent Operation
    NOISE: Less Than85dB(A) Oil Yield: 40-45%
    Reactor Material: Q245R Boiler Steel Working Mode: Fully Continuous 24 Hours
    Capacity: 30ton Per Day

    30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant​


     waste tyre pyrolysis plant adopt the latest pyrolysis technology and process the waste tyres/plastics with high temperature in a oxygen-free condition. Through the waste tyre pyrolysis process, you can get fuel oil, carbon black, steel wire and combustible gas from waste tyres.
    Waste Tire Pyrolysis Plant can convert various waste tires and rubber into pyrolysis oil, carbon black, steel wires and combustible gas.



    Features of Continuous Tyre Pyrolysis Plant:
    1.Fully automatic and 24 hours continuous production adopting advanced technology can produce good quality fuel oil.
    2.Full Automatic,no need labor ,high-temperature and enclosed discharging,which is enviromental-friendly,clean and dust-free.
    3.Unique anti-sticking devices ,which can achieve continuous production of special materials.
    4.Large capacity with 20-50 tons per day ;Durling production,there is no need for fule because the non-condensable gas produced by pyrolysis can support the whole process of production.
    5.Environmental-friendly and pollution-free(general hazardous waste processing standards),with national patent smoke scrubbers which can remove acid gas and dust from smoke.

    Technical Specification

    No Specification Fully continuous waste tyre/plastic/rubber prolysis plant
    1 Model HNJZ-30 HNJZ-40 HNJZ-50 HNJZ-60
    2 Working type Fully continuous Fully continuous Fully continuous Fully continuous
    3 Raw Material Waste tires,waste rubber,waste plastic,waste acrylic,oily sludge
    4 24 hour handling capacity 30T 40T 50T 60T
    5 24 hour oil production 14T 18T 22T 27T
    6 Heating way Directly heating Directly heating Directly heating Directly heating
    7 Working pressure Ordinary pressure Ordinary pressure Ordinary pressure Ordinary pressure
    8 Cooling way Water cooling Water cooling Water cooling Water cooling
    9 Water consumption 10T/H 12T/H 16T/H 20T/H
    10 Noise ≤85DB(A) ≤85DB(A) ≤85DB(A) ≤85DB(A)
    11 Total weight 60T 68T 75T 80T
    12 Area 47*10*9M 53*10*9M 55*10*9M 58*10*9M

    Usage of the end products:

    Crude carbon black ----make briquettes for heating use;make bricks to pave street

    Pyrolysis fuel oil------ sell directly for heating oil; to refine into diesel grade oil.

    Sync gas ------recycle to heat machine during production.
    Applications
    It is applied to extract fuel oil from waste tires, rubbers, plastics, soles, life garbage, cable skin and so on .
    seperating crude carbon black, steel wires. the sync gas produced can also be recycled to use as fuel to heat reactor, considerable cost of tire plastic plant.



    Q: What's environmental pollution problems during the conversion process?

    A:The environmental problem includes waste water, waste gas and waste solid.

    Q:How to assure the reactor safety?

    A: Our reactor is made by automatic welder machine. Welding technology and latest X- ray testing and flaw detection to protect gas from leak.

    Q:How to solve the environmental problem when operating the reactor?

    A:1.We have the closed discharging system and it is compete closed no fly ash and no pollution.

    2.The water seal is also a gas purifier, when waste gas go through the water seal, some pyro-gas will be cooled down and the combustible gas will be sent into the heating system as fuel.

    3.The whole process is no solid waste.

    4.The emission control system can deal with waste flue gas with no pollution to environment.

    30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant
    30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant
    30 Ton Per Day Full Continuous Waste Rubber Tyre Pyrolysis Oil Plant
