30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant

30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant

    • 30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant
    • 30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant
    • 30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant
    • 30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant
    • 30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant
  • 30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant

    Product Details:

    Place of Origin: China
    Brand Name: HNJZ
    Certification: CE
    Model Number: 50ton

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 sets
    Price: USD 300000
    Packaging Details: naked package
    Delivery Time: 30 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: USD 30 sets per month
    Contact Now
    Detailed Product Description
    Type: Waste Tire Pyrolysis Plant Raw Material: Waste Rubber ,Waste Tire,waste Plastic
    End Product: Fuel Oil, Carbon Black, Steel Wire, Sync Gas Structure: Horizontal Rotation
    Fuel Choice: Coal,wood,gas ,oil Operating Mode: Intermittent Operation
    NOISE: Less Than85dB(A) Oil Yield: 40-45%
    Reactor Material: Q245R Boiler Steel Working Mode: Fully Continuous 24 Hours
    Capacity: 50ton Per Day

    30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant



    Continuous Waste Tyre Pyrolysis Plant

    Pyrolysis Plant is used for recycling waste tire, waste plastic, waste rubber to fuel oil. According to the actual situation in every country and district, we developed different models of Batch Pyrolysis Plants for waste tires, rubber and plastic with daily capacity 25-40 tons.

    Advantages

    1.Outstanding Features:

    a. The reactor need preheat at the first when the machine starts producing.

    b. 24h continuous working for 20-30 days without any stops.

    c. No need fuels, sync gas is recycled during the operation.

    d. Large daily capacity:20-25T/D;25-30T/D

    e. New desing of vertical condensers. Good oil quality with high profit.

    f. Low requirement on the raw materials.

    2. Security:

    a: Adopting automatic submerged-arc welding technology

    b: All of the welding will be detected by the ultrasonic nondestructive testing method to ensure the welding quality and the

    welding shape.

    c: Adopting manufacture process controlling system on the quality, every manufacture process, manufacture date, etc.

    d: Equipped with anti-explosion device, safety valves, emergency valves, pressure and temperature meters, as well as the alarming

    system.

    3. Environmental-friendly:

    a: Emission Standard: Adopting special gas scrubbers to remove acid gas and dust from smoke

    b: Smell during operation: Fully enclosed during the operation

    c: Water pollution: No pollution at all.

    d: Solid pollution: the solid after pyrolysis is the crude carbon black and steel wires which can be deep-processed or sold

    directly with its value.

    Technical Specification

    NO. ITEM Technical Parameter
    1 Suitable Raw Materials Small pieces of Waste tyre,rubber,waste plastic<=10cm
    2 Operating Mode Fully Continuous Opreation
    3 Structure Horizontal Type
    4 Loading and discharging Fully automatic feeding and discharging under high temperature at same time
    5 Capacity(24h) 20ton, 30ton, 50ton, 80ton, 100ton
    6 Work Pressure Slightly Negative Pressure
    7 Oil Yield of tyres 40%-45%
    8 Reactor Rotation Speed 1R/M
    9 Power 50-60kw/h
    10 Cooling Method Cycle water
    11 Type of Drive Sprocket Wheel
    12 Heating Method Coal, tyre oil, gas
    13 NoisedB(A) <=85
    14 Main Reactor Weight(Mt) 15-18Mt
    15 Total Weight(Mt) 30—40Mt
    16 Installation Space Required 60m*30m
    17 Manpower 2persons/shift
    18 Shipment 1*40FR+3~4 HC
    19 Delivery time <=70Days



    Q: What's environmental pollution problems during the conversion process?

    A:The environmental problem includes waste water, waste gas and waste solid.



    Q:How to assure the reactor safety?

    A: Our reactor is made by automatic welder machine. Welding technology and latest X- ray testing and flaw detection to protect gas from leak.



    Q:How to solve the environmental problem when operating the reactor?

    A:1.We have the closed discharging system and it is compete closed no fly ash and no pollution.

    2.The water seal is also a gas purifier, when waste gas go through the water seal, some pyro-gas will be cooled down and the combustible gas will be sent into the heating system as fuel.

    3.The whole process is no solid waste.

    4.The emission control system can deal with waste flue gas with no pollution to environment.

    30T~50T Fully Continuous Waste Plastic Scrap Tyre Oil Distillation Pyrolysis Plant
